Soap Wrapping Machine - WrappexD Gold + (Servo Model)

COMPLETE FULLY AUTOMATIC SOAP WRAPPING MACHINE 3 SERVO DRIVE MODEL WITH DUEL PAPER WRAPPER MECHANISM (WRAPPER + STIFFENER) WITH ALL THE CRITICAL PARTS & ACCESSORIES;

MODEL:  WRAPPEX GOLD-3X (732225FC0300) DESIGN SPEED: 225 PPM (Design Speed)

MECHANISM: 3 SERVO MODEL

  • VF Drive For Speed Controlling, Better And Smooth Soap Cake Handling At High / Low Speed
  • 7 Inch HMI Screen Controller With Programmable Memory
  • Secured With Password
  • PLC With Memory - Save And Load Your Stored Recipe Any Time
  • 3 Servo (3X Model) Motor Drive At Cut Off Section (For Wrapper And Stiffener) & Infeed Conveyor
  • Infeed Belt For Automatic Soap Feeding.
  • Conveyor Belts And Cut Of Knives • Auto - Stop Sensors (No Soap No Run)
  • In-Feed Over Head Chain Pusher And Two Way Infeed Belt Mechanism For Ease & Gentle In Soap Conveyance
  • Anti-Marking Mechanism At Infeed Belt And Over Head Pushers.
  • Auto Lubricating
  • Double Unwinding Spools For Both Wrapper Section And Stiffener Section
  • Easy To Lock Spool Lock (Flick N Lock)
  • Easy Reel Centralizing Mechanism
  • Wrappex Gold Model > Equipped With Extended & Additional Top Heaters And Two Side Heaters; Additional Cooling Zone
  • Digital Temperature Controller.
  • High Quality Eye Mark Sensor
  • Colour Mark Sensor At Infeed Conveyor Interlock With Mechanical Clutch.
  • High Quality Heaters With Branded Temperature Controllers
  • SS 304 Fasteners & Washers
  • Safety Guarding SS Doors And Acrylic Sheet Covering To Critical Parts
  • With Pre-Loaded Change Part For One Size Soap
  • Additional Set Of Heaters (2 Nos Side + 1 Nos Top Heater)
  • Additional Tool Kit With Essential Spare Parts And Tools, Gears
  • Power Consumption : 2.5 HP • Machine Weight: 1500 Kgs (approx)
  • Machine Dimensions: Length : 4000 Mm X Width : 1600 Mm X Height: 2000 Mm (approx)
