HORIZONTAL FLOW WRAPPING MACHINE - FLOWRAP GOLD+++++ 5 SERVO MODEL WITH SMART CONVEYOR

HORIZONTAL FLOW WRAPPING MACHINE - FLOWRAP GOLD+++++ 5 SERVO MODEL WITH SMART CONVEYOR

HORIZONTAL FLOW WRAPPING MACHINE - MODEL: FLOWRAP GOLD+++++ (5 SERVO) MACHINE WITH SMART CONVEYOR.
FULLY AUTOMATIC  FLOW WRAPPING / PILLOW PACKING MACHINE WITH ALL THE CRITICAL PARTS & ACCESSORIES - FOUR SERVO MODEL
SPEED:    DESIGN SPEED 220  PPM *- FULLY SERVO CONTROLLED (* =DEPEND ON PRODUCT SHAPE, DESIGN, PACK WEIGHT, TYPE OF PACK)
MODEL:    FLOWRAP GOLD+++++ (5 SERVO MODEL)
THE MACHINE FULLY EQUIPPED WITH ALL THE CRITICAL & ESSENTIAL PARTS
AS BELOW;

  1.     AUTO FEEDING OF THE PRODUCT
  2.     SERVO DRIVE AT SMART CONVEYOR WITH PHOTOMATIC SENSOR, AUTO SPEED CONTROL, BETTER AND SMOOTH PRODUCT HANDLING AT HIGH / LOW SPEED
  3.     SERVO DRIVE AT WRAPPER PITCH AUTO CORRECTION SETTINGS
  4.     SERVO DRIVE AT INFEED CONVEYOR
  5.     SERVO DRIVE AT KNIEF / SEALING ZONE (CUT -OFF & SEAL)
  6.     SERVO AT COLLETOR AT OUTFEED - SERVO GEARBOX
  7.     AUTO-STOP SENSOR (NO PRODUCT NO RUN)
  8.     MITSUBISHI MAKE SERVO DRIVE WITH PLC, DIGITAL CONTROLLER
  9.     STRAIGHT DISCHARGE BELT WITH COLLETOR AT BACK
  10.     WITH EMERGENCY SPARE KIT AND TOOL BOX
  11.     HIGH QUALITY ANTI-SLIPPRY CONVEYOR BELTS
  12.     MAINTENANCE FREE AND EASE IN OPERATION MECHANISM
  13.     AUTO CLUTCH SYSTEM TO ELIMINATE WASTAGE
  14.     METALON  - MATERIAL HIGH STRENGTH PUSHERS
  15.     HEAT CONTROLLERS
  16.     7 INCH COLOUR TOUCH SCREEN H.M.I WITH PASSWORD PROTECTION
  17.     UNLIMITED RECIPE STORAGE
  18.     WIRING - ANCHOR
  19.     SWITCHES - L & T
  20.     EASY TO CHANGE COLLAR, FOLDER MECHANISM
  21.     QUICK-LOCK UNWINDING CHUCK MECHANISM
  22.     S.S. 304 CONTACT PARTS
  23.     S.S.304 GUARDING AND ACRYLIC SHEET GUARDING.

OPTIONAL:

  • FULL GUARDING WITH S.S. 304 & ACRYLIC SHEET
